86BYG250 Series Hybrid Stepper Motors
Appearance
![](86BYGfiles/image002.jpg)
Technical Parameters
Model |
Phase |
Current |
R |
L |
Step Angle |
Holding Torque |
Detent Torque |
Inertia |
Weight |
A |
Ω |
mH |
Degree |
N.m |
N.m |
Kg.cm^2 |
Kg |
86BYG250A |
2/4 |
1.7/3.6 |
0.23 |
2.5 |
0.9/1.8 |
1.2 |
0.08 |
0.64 |
1.6 |
86BYG250B |
4 |
0.65 |
6.9 |
0.9/1.8 |
2.4 |
0.15 |
1.3 |
2.6 |
86BYG250C |
4 |
1 |
7.4 |
0.9/1.8 |
3.6 |
0.25 |
1.9 |
3.8 |
Dimensions
![](86BYGfiles/image004.gif)
86BYG250
Model |
L |
86BYG250A |
61 |
86BYG250B |
93 |
86BYG250C |
135 |
Connection
Model |
Phase |
Earth |
A |
A' |
B |
B' |
C |
C' |
D |
D' |
Remarks |
86BYG250 |
4 |
/ |
Red
|
Yellow
|
White
|
Purple
|
Blue
|
Black
|
Brown
|
Green
|
8 Lines |
2 |
/ |
Red
|
Yellow
|
Green
|
Blue
|
|
|
|
|
4 Lines |
|
