HB205S 2-phase hybrid stepping driver
一、Features![](HB205SNfiles/image002.jpg)
-
AC24~50V or DC36~70V DC Power Supply
- Max 6A Phase Current Output
-
Using the AC servo motor current control modes to achieve a precise breakdown of the sinusoidal output current, completely solve the traditional stepper motor system low resonance, operating noise, small high-speed torque , low frequency starting shortcomings of stepper motor system and to be comparable to AC servo system.
- Robust to Parameters of Stepper Motors
- Selectalbe Microstep(16- switch)
- Selectable current setting (8- switch)
- Selectable Pulse Mode- 1 clk. or 2 clk. inputs
- Disable contro l(Free)
- Isolated Input (Photo-coupler)
- Holding Position when repowered
二、Adapter Motors
57、86、90 BYG Series 2-Phase hybrid Stepper motors
三、Inputs & Outputs
Label
|
Function
|
Note
|
CP+ |
Pulse Signal + |
Photo-coupler Input resistance 390 Ω, Rated 5V, 12mA, 2us minimum pulse width |
CP- |
Pulse Signal - |
CW+ |
Direction Signal + |
CW- |
Direction Signal - |
FRE+ |
Disable Signal + |
Photo-coupler ON: disable Output; OFF: Enable Output |
FRE- |
Disable Signal - |
ERR-C |
Error Output C of OC Gate |
Photo-coupler OC Output(Max 50V/20mA)。When error, C and E is short. |
ERR-E |
Error Output E of OC Gate |
POWER |
Power Indicator led |
Red |
TIMING |
Phase Origin Indicator |
Green |
ERROR |
Error Indicator led |
Red |
A |
A Output |
|
/A |
/A Output |
|
B |
B Output |
|
/B |
/B Output |
|
AC40V |
Power Supply |
Rated AC40V(AC24~50V/DC36~70V),3A |
Note:
non 5V signal request corresponding increase in external resistor(about 10mA Current)
四、Pulse Mode
DIP1 |
Pulse mode setting |
0 |
2-clk,CP+/CP-: CW Pulse ; CW+/CW-: CCW Pulse |
1 |
1-clk,CP+/CP-: Pulse Input; CW+/CW-: Direction(Level)
|
五、Current Setting
DIP2 3 4 |
Output Phase Current(A) |
000 |
6.0 |
001 |
5.5 |
010 |
5.0 |
011 |
4.5 |
100 |
4.0 |
101 |
3.5 |
110 |
3.0 |
111 |
2.5 |
六、Resolution Setting
DIP5 6 7 8 |
steps/tooth |
Steps/Rev |
0000 |
256 |
12800 |
0001 |
200 |
10000 |
0010 |
160 |
8000 |
0011 |
128 |
6400 |
0100 |
100 |
5000 |
0101 |
80 |
4000 |
0110 |
64 |
3200 |
0111 |
50 |
2500 |
1000 |
40 |
2000 |
1001 |
32 |
1600 |
1010 |
25 |
1250 |
1011 |
20 |
1000 |
1100 |
16 |
800 |
1101 |
10 |
500 |
1110 |
8 |
400 |
1111 |
4 |
200 |
Note:DIP“ON”=0, other Resolutions can be customized.
七、Connection
![](HB205SNfiles/image004.gif)
八、Dimensions
|
